0.6 Module 98 Teeth Brass Spur Gear with Step Cylindrical Transmission Gear 5mm Teeth Thickness 0.6M 98T Pinion Mechanical(6.35mm bore)
Product details
| Management number | 220411887 | Release Date | 2026/05/03 | List Price | $14.06 | Model Number | 220411887 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Material: Brass, Model: 0.6 module 98 teeth, pressure angle 20°Teeth Pitch: 1.88mm, Teeth depth: 1.35mm, Teeth thickness: 5mmTeeth diameter: 60mm, pitch diameter: 58.8mmStep diameter: 15mm-40mm (Note: the diameter of the step is not fixed, it varies according to the selection of the bore) Optional Hole: 10mm, 11mm, 12mm, 12.7mm, 13mm, 14mm, 15mm，16mm, 17mm, 18mm, 19mm, 20mm
- Material: Brass, Model: 0.6 module 98 teeth
- Teeth Pitch: 1.88mm, Teeth depth: 1.35mm, Teeth thickness: 5mm
- Teeth diameter: 60mm, pitch diameter: 58.8mm
- Brass Construction: Crafted from premium brass, our pinion gears boast exceptional wear resistance, superior strength, and remarkable hardness
- Easy Installation: Designed with a uniform diameter, our pinion gears are incredibly easy to install. The surface of the gear teeth facilitates straightforward assembly
| Brand Name | ELILANEY |
|---|---|
| Part Number | NAHAZCCYC-6.35MMBORE |
| Manufacturer | ELILANEY |
